| Art No. | SIZE | A | B | C | D | E | F | G |
| inch | mm | mm | mm | mm | mm | mm | mm | |
| S.EB15-0560 | 5X60 | 5 | 40 | 60 | 30 | 4.4 | 11 | 5 |
| S.EB15-0580 | 5X80 | 5 | 60 | 80 | 30 | 4.4 | 11 | 5 |
| S.EB15-05100 | 5X100 | 5 | 80 | 100 | 30 | 4.4 | 11 | 5 |
| S.EB15-0660 | 6X60 | 6 | 36.4 | 60 | 35 | 5.3 | 13 | 6 |
| S.EB15-0680 | 6X80 | 6 | 56.4 | 80 | 35 | 5.3 | 13 | 6 |
| S.EB15-0690 | 6X90 | 6 | 66.4 | 90 | 35 | 5.3 | 13 | 6 |
| S.EB15-06100 | 6X100 | 6 | 76.4 | 100 | 35 | 5.3 | 13 | 6 |
| S.EB15-0860 | 8X60 | 8 | 29 | 60 | 45 | 7.1 | 17 | 7.8 |
| S.EB15-0880 | 8X80 | 8 | 49 | 80 | 45 | 7.1 | 17 | 7.8 |
| S.EB15-08100 | 8X100 | 8 | 69 | 100 | 45 | 7.1 | 17 | 7.8 |
| S.EB15-08100 | 8X110 | 8 | 79 | 110 | 45 | 7.1 | 17 | 7.8 |
| S.EB15-08130 | 8X130 | 8 | 99 | 130 | 45 | 7.1 | 17 | 7.8 |
| S.EB15-1080 | 10X80 | 10 | 41 | 80 | 50 | 8.9 | 21 | 9.8 |
| S.EB15-1090 | 10X90 | 10 | 51 | 90 | 50 | 8.9 | 21 | 9.8 |
| S.EB15-10100 | 10X100 | 10 | 61 | 100 | 50 | 8.9 | 21 | 9.8 |
| S.EB15-10110 | 10X110 | 10 | 71 | 110 | 50 | 8.9 | 21 | 9.8 |
| S.EB15-10120 | 10X120 | 10 | 81 | 120 | 50 | 8.9 | 21 | 9.8 |
| S.EB15-10130 | 10X130 | 10 | 91 | 130 | 50 | 8.9 | 21 | 9.8 |
| S.EB15-10150 | 10X150 | 10 | 111 | 150 | 50 | 8.9 | 21 | 9.8 |
| S.EB15-12150 | 12X150 | 12 | 104 | 150 | 60 | 10.7 | 25 | 11.8 |
| S.EB15-12165 | 12X165 | 12 | 119 | 165 | 60 | 10.7 | 25 | 11.8 |
| S.EB15-12185 | 12X185 | 12 | 139 | 185 | 60 | 10.7 | 25 | 11.8 |
| S.EB15-16150 | 16X150 | 16 | 88 | 150 | 80 | 14.7 | 33 | 15.8 |
| S.EB15-16200 | 16X200 | 16 | 138 | 200 | 80 | 14.7 | 33 | 15.8 |
| S.EB15-20200 | 20X200 | 20 | 123 | 200 | 100 | 18.3 | 41 | 19.8 |
