| Engine HP&the year | Drive Type | Art No. | No. Blade | Diam. | Pitch | Rotation |
| 4-6 HP MFS4/5S/6S(4 stroke) M5B(2 stroke) | 12 tooth spline
| MEGARA Series | ||||
| AL.M0601-7.8-6-RH | 3 | 7.8 | 6 | RH | ||
| AL.M0601-7.8-7-RH | 3 | 7.8 | 7 | RH | ||
| AL.M0601-7.8-8-RH | 3 | 7.8 | 8 | RH | ||
| AL.M0601-7.8-9-RH | 3 | 7.8 | 9 | RH | ||
| 8-9.8HP 8hp(2&4 stroke)...2005-newer 9.8hp(2&4 stroke)...2005-newer MFS8/9.8(4 stroke);NSF8 /9.8(4 stroke) all years | 12 tooth spline
| MEGARA Series | ||||
| AL.M0602-8.5-6.5-RH | 3 | 8.5 | 6.5 | RH | ||
| AL.M0602-8.9-7-RH | 3 | 8.9 | 7 | RH | ||
| AL.M0602-8.5-7.5-RH | 3 | 8.5 | 7.5 | RH | ||
| AL.M0602-8.9-8.5-RH | 3 | 8.9 | 8.5 | RH | ||
| AL.M0602-8.9-9.5-RH | 3 | 8.9 | 9.5 | RH | ||
| Stella Series（High Thrust） | ||||||
| AL.M0603-8.7-5-RH | 4 | 8.7 | 5 | RH | ||
| AL.M0603-8.7-7-RH | 4 | 8.7 | 7 | RH | ||
| 9.9-18HP 9.9hp(2 stroke)…1984-newer 9.9hp(4 stroke)…2000-2003 12hp…1985-1988 15hp(2 stroke)…1985-newer 15hp(4 stroke)...2000-newer 18hp(2 stroke)...1985-newer 18hp(4 stroke)…2001-2008 20hp(4 stroke)...2007-newer MFS9.9/15/18/20; MSFMFS9.9/15/18/20 |
A GROUP 14 tooth spline
| SEMA Series | ||||
| AL.M0604-9 1/4-7-RH | 3 | 9 1/4 | 7 | RH | ||
| AL.M0604-9 1/4-8-RH | 3 | 9 1/4 | 8 | RH | ||
| AL.M0604-9 1/4-9-RH | 3 | 9 1/4 | 9 | RH | ||
| AL.M0604-9 1/4-10-RH | 3 | 9 1/4 | 10 | RH | ||
| AL.M0604-9 1/4-11-RH | 3 | 9 1/4 | 11 | RH | ||
| AL.M0604-9 1/4-12-RH | 3 | 9 1/4 | 12 | RH | ||
| Stella Series（High Thrust） | ||||||
| AL.M0605-10-5-RH | 4 | 10 | 5 | RH | ||
| AL.M0605-10-7-RH | 4 | 10 | 7 | RH | ||
| 25-30HP 3" Gearcase 25hp…1986-2001 30hp…1985-2001 25hp(4 stroke)…2002-newer 30hp(4 stroke)…2002-newer MFS 25/30(4 stroke) NSF25/30(4 stroke) |
B GROUP 10 tooth spline
| Stella Series | ||||
| AL.M0606-9.9-9-RH | 3 | 9.9 | 9 | RH | ||
| AL.M0606-9.9-10-RH | 3 | 9.9 | 10 | RH | ||
| AL.M0606-9.9-11-RH | 3 | 9.9 | 11 | RH | ||
| AL.M0606-9.9-12-RH | 3 | 9.9 | 12 | RH | ||
| AL.M0606-9.9-13-RH | 3 | 9.9 | 13 | RH | ||
| AL.M0606-9.9-14-RH | 3 | 9.9 | 14 | RH | ||
| Stella Series（High Thrust） | ||||||
| AL.M0607-10-5-RH | 4 | 10 | 5 | RH | ||
| AL.M0607-10-7-RH | 4 | 10 | 7 | RH | ||
| 35-50HP 3-1/4" Gearcase 35hp(35B only)...thru 1984 40hp...1984-newer MFS 40hp...2015-newer 50hp(All except 50C)...1992-newer |
C GROUP 13 tooth spline
| YANTA Series | ||||
| AL.M0608-12 1/4-9-RH | 3 | 12 1/4 | 9 | RH | ||
| AL.M0608-11 3/4-10-RH | 3 | 11 3/4 | 10 | RH | ||
| AL.M0608-11 5/8-11-RH | 3 | 11 5/8 | 11 | RH | ||
| AL.M0608-11 3/8-12-RH | 3 | 11 3/8 | 12 | RH | ||
| AL.M0608-11 1/8-13-RH | 3 | 11 1/8 | 13 | RH | ||
| AL.M0608-11 1/4-14-RH | 3 | 11 1/4 | 14 | RH | ||
| AL.M0608-11-15-RH | 3 | 11 | 15 | RH | ||
| MEGARA Series | ||||||
| AL.M0609-10.6-11-RH | 4 | 10.6 | 11 | RH | ||
| AL.M0609-10.6-12-RH | 4 | 10.6 | 12 | RH | ||
| AL.M0609-10.3-13-RH | 4 | 10.3 | 13 | RH | ||
| AL.M0609-10.1-14-RH | 4 | 10.1 | 14 | RH | ||
| AL.M0609-10.1-15-RH | 4 | 10.1 | 15 | RH | ||
