Art No. | SIZE | WIRE | A | D | H | D1 | D2 | L1 | L2 | L3 | BL | Weight |
mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | tons | kg/pc | |
S.RS06-04 | M4 | 2 | 5.5 | 4 | 8 | 2.2 | 4.8 | 130 | 190 | 24 | 0.50 | 0.030 |
S.RS06-05 | M5 | 2.5 | 6.5 | 5 | 10 | 2.2 | 5.5 | 150 | 210 | 32 | 0.80 | 0.050 |
S.RS06-06 | M6 | 3 | 7.5 | 6 | 10 | 3.3 | 6.35 | 180 | 250 | 39 | 1.25 | 0.085 |
S.RS06-08 | M8 | 4 | 11 | 8 | 11 | 4.3 | 7.5 | 210 | 285 | 45 | 2.35 | 0.160 |
S.RS06-10 | M10 | 5 | 12 | 9 | 14 | 5.3 | 9 | 240 | 330 | 52 | 3.50 | 0.280 |
S.RS06-12 | M12 | 6 | 14 | 12 | 20 | 6.4 | 12.6 | 300 | 410 | 64 | 5.10 | 0.550 |
S.RS06-14 | M14 | 7 | 15 | 12 | 22 | 7.4 | 14.2 | 330 | 450 | 70 | 5.90 | 0.680 |
S.RS06-16 | M16 | 8 | 17 | 16 | 26 | 8.4 | 16 | 370 | 510 | 80 | 8.00 | 1.200 |
S.RS06-20 | M20 | 10 | 20 | 19 | 30 | 10.5 | 18 | 410 | 560 | 90 | 13.00 | 2.370 |
S.RS06-22 | M22 | 14 | 22 | 22 | 35 | 14.7 | 25 | 540 | 720 | 140 | 17.00 | 5.650 |
S.RS06-24 | M24 | 16 | 25 | 25 | 38 | 16.9 | 28 | 630 | 860 | 160 | 20.00 | 6.200 |
S.RS06-27 | M27 | 19 | 30 | 28 | 41 | 20 | 34.5 | 720 | 950 | 200 | 25.50 | 11.850 |
S.RS06-30 | M30 | 22 | 35 | 32 | 52 | 23.2 | 40.5 | 820 | 1080 | 230 | 31.00 | 16.750 |
S.RS06-36 | M36 | 26 | 35 | 35 | 52 | 27.5 | 46 | 910 | 1185 | 280 | 43.00 | 22.420 |
