| Engine HP&the year | Drive Type | OEM # | No. Blade | Diam. | Pitch | Rotation |
| 2A/B | Pin Drive
| YANTA Series | ||||
| AL.M0301-7 1/4-5-RH | 3 | 7 1/4 | 5 | RH | ||
| F2.5A/3A | 9 tooth spline | AL.M0301-7 1/4-6-RH | 3 | 7 1/4 | 6 | RH |
| 4A/5C/F4A | AL.M0301-7 1/2-7-RH | 3 | 7 1/2 | 7 | RH | |
| AL.M0301-7 1/2-8-RH | 3 | 7 1/2 | 8 | RH | ||
| 6-9.9HP 6hp(2 stroke)…1986-2000 8hp(2 stroke)…1986-2009 F9.9(4 stroke)…2008-newer F6(4 stroke)…2001-2010 F8(4 stroke)…2001-newer |
7 tooth spline
| YANTA Series | ||||
| AL.M0302-8 1/2-6 1/2-RH | 3 | 8 1/2 | 6 1/2 | RH | ||
| AL.M0302-8 1/2-7 1/2-RH | 3 | 8 1/2 | 7 1/2 | RH | ||
| AL.M0302-8 1/2-8 1/2-RH | 3 | 8 1/2 | 8 1/2 | RH | ||
| AL.M0302-8 1/2-9 1/4-RH | 3 | 8 1/2 | 9 1/4 | RH | ||
| Stella Series （High Thrust） | ||||||
| AL.M0303-8.7-5-RH | 4 | 8.7 | 5 | RH | ||
| AL.M0303-8.7-7-RH | 4 | 8.7 | 7 | RH | ||
| 9.9-20HP 2-1/2" Gearcase T8, T9.9...all years F9.9(4 stroke)...2000-2007 F15(4 stroke)...1998-newer F20(4 stroke)...2007-newer 9.9hp(2 stroke)...1984-2009 15hp(2 stroke)...1984-2009 F15C...2007-newer |
A GROUP 8 tooth spline
| YANTA Series | ||||
| AL.M0304-9 1/4-8-RH | 3 | 9 1/4 | 8 | RH | ||
| AL.M0304-9 1/4-9-RH | 3 | 9 1/4 | 9 | RH | ||
| AL.M0304-9 1/4-10-RH | 3 | 9 1/4 | 10 | RH | ||
| AL.M0304-9 1/4-11-RH | 3 | 9 1/4 | 11 | RH | ||
| AL.M0304-9 1/4-12-RH | 3 | 9 1/4 | 12 | RH | ||
| AL.M0304-9 1/4-8-RH | 3 | 9 1/4 | 8 | RH | ||
| AL.M0304-9 1/4-9-RH | 3 | 9 1/4 | 9 | RH | ||
| AL.M0304-9 1/4-9 3/4-RH | 3 | 9 1/4 | 9 3/4 | RH | ||
| AL.M0304-9 1/4-10 1/2-RH | 3 | 9 1/4 | 10 1/2 | RH | ||
| AL.M0304-9 1/4-12-RH | 3 | 9 1/4 | 12 | RH | ||
| Stella Series（High Thrust） | ||||||
| AL.M0305-10-5-RH | 4 | 10 | 5 | RH | ||
| AL.M0305-10-7-RH | 4 | 10 | 7 | RH | ||
| 20-30HP 3" Gearcase 20hp…1996-1997 F25(4 stroke)…1998-2006; 2010-newer 25hp…1980-newer 30hp…1979-2002 |
B GROUP 10 tooth spline
| YANTA Series | ||||
| AL.M0306-9 7/8-9-RH | 3 | 9 7/8 | 9 | RH | ||
| AL.M0306-9 7/8-10 1/2-RH | 3 | 9 7/8 | 10 1/2 | RH | ||
| AL.M0306-9 7/8-11 1/4-RH | 3 | 9 7/8 | 11 1/4 | RH | ||
| AL.M0306-9 7/8-12-RH | 3 | 9 7/8 | 12 | RH | ||
| AL.M0306-9 7/8-13-RH | 3 | 9 7/8 | 13 | RH | ||
| AL.M0306-9 7/8-14-RH | 3 | 9 7/8 | 14 | RH | ||
| Stella Series（High Thrust） | ||||||
| AL.M0307-10-5-RH | 4 | 10 | 5 | RH | ||
| AL.M0307-10-7-RH | 4 | 10 | 7 | RH | ||
| 25-60HP 3-1/2" Gearcase T25hp...2010-newer F30(4 stroke)...2001-2005 ; 2015-newer 40hp(C40)...1984-newer 48hp...1995-2000 50hp(Not T50)...1984-newer F40(4 stroke)...1999-newer F50(4 stroke)...1995-newer 55hp...1976-1995 60hp...1976-1991 F60(4 stroke)...1999-newer |
C GROUP 13 tooth spline
| YANTA Series | ||||
| AL.M0308-12 1/4-9-RH | 3 | 12 1/4 | 9 | RH | ||
| AL.M0308-11 3/4-10-RH | 3 | 11 3/4 | 10 | RH | ||
| AL.M0308-11 5/8-11-RH | 3 | 11 5/8 | 11 | RH | ||
| AL.M0308-11 3/8-12-RH | 3 | 11 3/8 | 12 | RH | ||
| AL.M0308-11 1/8-13-RH | 3 | 11 1/8 | 13 | RH | ||
| AL.M0308-11 1/4-14-RH | 3 | 11 1/4 | 14 | RH | ||
| AL.M0308-11-15-RH | 3 | 11 | 15 | RH | ||
| MEGARA Series | ||||||
| AL.M0309-10 7/8-11-RH | 3 | 10 7/8 | 11 | RH | ||
| AL.M0309-10 5/8-12-RH | 3 | 10 5/8 | 12 | RH | ||
| AL.M0309-10 3/4-12-RH | 3 | 10 3/4 | 12 | RH | ||
| AL.M0309-10 3/8-13-RH | 3 | 10 3/8 | 13 | RH | ||
| AL.M0309-10 1/2-13-RH | 3 | 10 1/2 | 13 | RH | ||
| AL.M0309-10 1/4-14-RH | 3 | 10 1/4 | 14 | RH | ||
| AL.M0309-10 3/8-14-RH | 3 | 10 3/8 | 14 | RH | ||
| AL.M0309-10 1/8-15-RH | 3 | 10 1/8 | 15 | RH | ||
| MEGARA Series | ||||||
| AL.M0310-10.6-11-RH | 4 | 10.6 | 11 | RH | ||
| AL.M0310-10.6-12-RH | 4 | 10.6 | 12 | RH | ||
| AL.M0310-10.3-13-RH | 4 | 10.3 | 13 | RH | ||
| AL.M0310-10.1-14-RH | 4 | 10.1 | 14 | RH | ||
| AL.M0310-10.1-15-RH | 4 | 10.1 | 15 | RH | ||
| 50-130HP 4-1/4" Gearcase T50(4 stroke)...1996-newer 60hp(C60/E60/P60)...1992-2005 T60(4 stroke)...2003-newer 70hp...1984-newer F70(4 stroke)...2010-newer 75hp(C75/E75/P75)...1994-1999 F75(4 stroke)...2003-newer 80hp...1997 F80(4 stroke)...1999-2002 85hp...1991-1997 90hp(C90)...1984-newer F90(4 stroke)...1999-newer F100(4 stroke)...1999-2002 115hp(C115/P115)...1984-newer F115(4 stroke)...2000-newer 130hp...1984-2003 |
D GROUP 15 tooth spline
| YANTA Series (Semi Cleaver Blade) | ||||
| AL.M0311-14-9-RH | 3 | 14 | 9 | RH | ||
| AL.M0311-14-11-RH | 3 | 14 | 11 | RH | ||
| AL.M0311-13 5/8-12-RH | 3 | 13 5/8 | 12 | RH | ||
| AL.M0311-13 5/8-13-RH | 3 | 13 5/8 | 13 | RH | ||
| AL.M0311-13 5/8-14-RH | 3 | 13 5/8 | 14 | RH | ||
| AL.M0311-13 1/2-15-RH | 3 | 13 1/2 | 15 | RH | ||
| AL.M0311-13 1/4-17-RH | 3 | 13 1/4 | 17 | RH | ||
| AL.M0311-13-19-RH | 3 | 13 | 19 | RH | ||
| AL.M0311-12 5/8-21-RH | 3 | 12 5/8 | 21 | RH | ||
| YANTA Series DUAL THRUST | ||||||
| AL.M0312-14-9-RH | 3 | 14 | 9 | RH | ||
| AL.M0312-14-11-RH | 3 | 14 | 11 | RH | ||
| MEGARA Series | ||||||
| AL.M0313-13.8-10-RH | 4 | 13.8 | 10 | RH | ||
| AL.M0313-13.8-11-RH | 4 | 13.8 | 11 | RH | ||
| AL.M0313-13.8-13-RH | 4 | 13.8 | 13 | RH | ||
| AL.M0313-13.4-15-RH | 4 | 13.4 | 15 | RH | ||
| AL.M0313-13-17-RH | 4 | 13 | 17 | RH | ||
| AL.M0313-12.5-19-RH | 4 | 12.5 | 19 | RH | ||
| 150-300HP 4-3/4" Gearcase 150hp...1986-newer F150(4 stroke)...2004-newer 175hp...1984-newer F175(4 stroke)...2014-newer 200hp...1984-newer 200hp(VMAX)...2001 F200(4 stroke)...2002-newer VF200V-MAX SHO...2010-newer 220hp(Special)...1987-1988 225hp(excel)...1980-newer 225hp...1986-newer F225(4 stroke)...2002-newer VF225 VMAX SHO...2010-newer 250hp...1990-newer 250hp(VMAX)...2001-newer F250HP Include VMAX and Offshore F250(4 stroke,Includes Offshore)...2002-newer 300HP(2 stroke V6 Engine)...2004-2007 F300 Offshore (4 stroke V6 Engine)...2010-newer Sterndrive 3.0L-7.47L |
E GROUP 15 tooth spline
| YANTA Series | ||||
| AL.M0314-15 1/4-15-RH | 3 | 15 1/4 | 15 | RH | ||
| AL.M0314-14 1/2-17-RH | 3 | 14 1/2 | 17 | RH | ||
| AL.M0314-14-19-RH | 3 | 14 | 19 | RH | ||
| AL.M0314- 13 3/4-21-RH | 3 | 13 3/4 | 21 | RH | ||
| MEGARA Series | ||||||
| AL.M0315-16-11-RH | 3 | 16 | 11 | RH | ||
| AL.M0315-16-13-RH | 3 | 16 | 13 | RH | ||
| AL.M0315-15 1/4-15-RH | 3 | 15 1/4 | 15 | RH | ||
| AL.M0315-15-17-RH | 3 | 15 | 17 | RH | ||
| AL.M0315-14 1/2-19-RH | 3 | 14 1/2 | 19 | RH | ||
| AL.M0315-14 1/4-21-RH | 3 | 14 1/4 | 21 | RH | ||
| AL.M0315-14-23-RH | 3 | 14 | 23 | RH | ||
| Torquemaster Series | ||||||
| AL.M0316-15-13-RH | 4 | 15 | 13 | RH | ||
| AL.M0316-15-15-RH | 4 | 15 | 15 | RH | ||
| AL.M0316-14 1/2-17-RH | 4 | 14 1/2 | 17 | RH | ||
| AL.M0316-14 1/4-19-RH | 4 | 14 1/4 | 19 | RH | ||
| AL.M0316-14-21-RH | 4 | 14 | 21 | RH | ||
