S.M24 MERCURY STAINLESS STEEL Propeller

S.M24 MERCURY STAINLESS STEEL Propeller


Technical parameters

Engine HP&the year Drive TypeArt No.No. BladeDiam.PitchRotation
6-15HP
2-1/2" Gearcase
6, 8, 9.9 and 15 HP 2‑Strokes...1986 & Newer
10, 15 HP Seapro/Marathon...1995-2010
8/9.9 HP (Not Bigfoot) 4‑Strokes...2002‑2004

15 HP(2&4 Stroke)...1989‑2006

(FORCE)9.9&15HP...1996-1998

A GROUP
8 tooth spline
SEMA Series
S.M2401-9 1/4-9-RH-839 1/49RH
S.M2401-9 1/4-10-RH-839 1/410RH
S.M2401-9 1/4-11-RH-839 1/411RH
S.M2401-9 1/4-12-RH-839 1/412RH
9.9-20HP
2-1/2" Gearcase
9.9 CT/Bigfoot Model Year 2005 and Newer
15/20 HP 4‑Stroke 2007 and Newer
A GROUP
14 tooth spline
SEMA Series
S.M2401-9 1/4-9-RH-1439 1/49RH
S.M2401-9 1/4-10-RH-1439 1/410RH
S.M2401-9 1/4-11-RH-1439 1/411RH
S.M2401-9 1/4-12-RH-1439 1/412RH
25-30HP
3" Gearcase
25hp...1980-1984
28hp...1976-1979
30hp...1979-1990
25hp(4 stroke/not bigfoot)…2006-newer
30hp(4 stroke/not bigfoot)…2006-newer
B GROUP
10 tooth spline
SEMA Series
S.M2402-10-11-RH31011RH
S.M2402-10-12-RH31012RH
S.M2402-10-13-RH31013RH
S.M2402-10-14-RH31014RH
S.M2402-10-15-RH31015RH
25-70HP
3-1/4" Gearcase
25hp Bigfoot(4 stroke)...1999-2005
30hp Bigfoot(4 stroke)...2010-newer
30hp(2&4 stroke)...1994-2005
30hp(sea Pro/Marathon)...1994-newer
35hp...1984-1989
402&500 Models...1974-1984
40hp(2&4 stroke/not bigfoot)...1977-newer
40hp(Sea Pro/Marathon)...1977-newer
45hp...1986-1989
48hp(Mariner)...all years
50hp(2&4 stroke/not bigfoot)...1977-newer
55hp(Mercury/Sea Pro/Marathon)...1995-newer

60hp(4 stroke)(not bigfoot or Sea Pro/Marathon)

...1978-newer

60hp(2 stroke)...1978-newer

70hp(Model 700)...1983

Force40/50hp...1995-1998
70hp...1991-1995
75hp...1996-1998
C GROUP
13 tooth spline

Classic Pressed-In Rubber bush type.
Stella Series
S.M2403-12 1/4-9-RH312 1/49RH
S.M2403-11 1/2-11-RH311 1/211RH
S.M2403-11 5/8-12-RH311 5/812RH
S.M2403-11 1/2-13-RH311 1/213RH
S.M2403-11 3/8-14-RH311 3/814RH
S.M2403-11 1/4-15-RH311 1/415RH
MEGARA Series
S.M2403-10 7/8-11-RH310 7/811RH
S.M2403-10 3/4-12-RH310 3/412RH
S.M2403-10 1/2-13-RH310 1/213RH
S.M2403-10 3/8-14-RH310 3/814RH
S.M2403-10 1/4-15-RH310 1/415RH
